Sensor performance

Field proven MKS quadrupole mass analyzers, with twin filaments as standard, ensure minimum downtime during critical diagnostic testing. The RGA is available with an optional dual detector including a faraday detector and microchannel plate electron multiplier for detection to e^-14mbar.

Electronics performance

Data acquisition occurs through all solid state, wide dynamic range, fast settling detector electronics. This technology prevents large peaks from causing false positive measurements on small peaks. Temperature stabilized critical components mean that signal stability and baseline drift are improved, allowing the unit to be used without frequent recalibration if the vacuum chamber is stable but ambient air temperature fluctuates.

Built-in web application

A web interface using industry standard technology allows control of the e-Vision 2 as well as calibration, operation and data export through a non platform-specific web browser from anywhere on a network. Using the ASCII protocol and TCP-IP communication, any third party software can send and receive commands and data from the e-Vision 2.

EasyView software

In addition to the standard, built-in web applications, software control is also available through an optional Windows application, offering the best possible fit to any customer requirement. The field proven software provides basic RGA controls but with more functionality than the built-in web application.

• Store RGA data and recall it back into the Recall viewer
• Annotate graphs with notes
• Run several RGAs from one software package
